| Motherboard | ASRock Z790M-ITX WiFi |
| CPU | Intel Core i5-14500 3.5GHz (14C/20T) 24MB Cache, 5.3GHz Turbo |
| Chipset | Intel Z790 Chipset |
| Memory | 2 x DDR5 DIMM Slots, Max. 128GB, DDR5 |
| Graphics | Intel Xe Graphics Architecture (Gen 12) 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz |
| Expansion Slots |
CPU
1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode Chipset 1 x Vertical M.2 Socket (Key E) |
| Storage | CPU 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes* 4 x SATA3 6.0 Gb/s Connectors *Supports Intel Volume Management Device (VMD) Supports NVMe SSD as boot disks |
| USB |
Rear USB (Total 6 ports)
4 x USB 3.2 Gen2 Type-A 1 x USB 3.2 Gen2x2 Type-C 1 x USB 2.0 Front USB (Total 5 ports) 1 x USB 3.2 Gen2x2 Type-C 2 x USB 3.2 Gen1 2 x USB 2.0 |
| Back Panel I/O Ports | 7.1 CH HD Audio (Realtek ALC897 Audio) 2 x Antenna Ports 1 x HDMI Port 1 x DisplayPort 1.4 1 x Optical SPDIF Out Port 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) 1 x USB 2.0 Port 1 x 2.5 Gigabit LAN Intel I226V 1 x Gigabit LAN Intel I219V 1 x Line Out Jack 1 x Microphone Input Jack |
| Wireless/Bluetooth | Wi-Fi 6E Bluetooth 5.3 |
| Note | Specifications and features may differ depending on the system configuration. |
