| Motherboard |
Asus ROG STRIX Z890-E GAMING WIFI |
| CPU |
Intel Core Ultra 9 285K 3.7GHz (Up To 5.7GHz Turbo) 24 Core
|
| Chipset |
Intel Z890 Chipset |
| Memory |
4 x DIMM Slots, Max. 192GB
|
| Graphics |
1 x DisplayPort
1 x HDMI Port
2 x Intel Thunderbolt 4 Support DisplayPort And Thunderbolt Video Outputs
|
| Expansion Slots |
1 x PCIe 5.0 x16 Slot (Supports x16 Or x8/x4/x4 Modes)
1 x PCIe 4.0 x16 Slot (Supports x4 Mode)
|
| Storage |
7 x M.2 Slots And 4 x SATA 6Gb/s Ports
|
| USB |
Rear USB (Total 14 Ports)
2 x Thunderbolt 4 (2 x USB Type-C)
9 x USB 10Gbps ports (7 x Type-A + 1 x USB Type-C* + 1 x USB Type-C With Up To 30W PD Fast-charge)**
3 x USB 5Gbps Ports (3 x Type-A)
Front USB (Total 11 Ports)
1 x USB 20Gbps connector (Supports USB Type-C)
2 x USB 5Gbps Headers Support Additional 4 USB 5Gbps Ports
3 x USB 2.0 Headers Support Additional 6 USB 2.0 Ports
* USB Type-C Power Delivery Output: 5V/3A
** USB Type-C Power Delivery Output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2A.
|
| Back Panel I/O Ports |
ROG SupremeFX 7.1 Surround Sound High Definition Audio
2 x Thunderbolt4 (2 x USB Type-C)
9 x USB 10Gbps Ports (7 x Type-A + 1 x USB Type-C + 1 x USB Type-C With Up To 30W PD Fast-charge)
3 x USB 5Gbps Ports (3 x Type-A)
1 x DisplayPort
1 x HDMI Port
1 x Wi-Fi Module
1 x Realtek 5GbE
2 x Gold-Plated Audio Jacks
1 x Optical S/PDIF Out Port
1 x BIOS FlashBack Button
1 x Clear CMOS Button
|
| Wireless/Bluetooth |
Wi-Fi 7
Bluetooth v5.4
|
